Autodesk Inventor 2018 Working with 3D Annotations & Model-Based Definition: Autodesk Authorized Publisher - Paperback

by Ascent -. Center for Technical Knowledge (Author)

Autodesk^(R) Inventor^(R) 2018: Working with 3D Annotations & Model-Based Definition teaches experienced Autodesk Inventor users how to create 3D annotations to support the visual presentation of annotations in 3D PDF format and a Model-based Definition (MBD) workflow.

The geometry designed in a 3D CAD modeling environment is created perfectly. During the manufacturing stage, it is not possible to achieve the same perfection. Variations in size, feature location, and orientation are unavoidable. This learning guide instructs how to use the tools in Autodesk Inventor 2018 to create 3D annotations that communicate dimensional and GD&T data, hold/thread notes, surface texture requirements, and informational text-based annotations; all of which aim to improve manufacturing accuracy. Additionally, this learning guide explains how you can share your 3D annotated models as 3D PDFs, as STEP files for use by other software applications, or in 2D drawing views.

Topics Covered

• Creating dimensional annotations.
• Creating hole/thread note annotations.
• Creating surface texture annotations.
• Creating text-based annotations to a model to communicate additional modeling information.
• Creating tolerance features to a model.
• Using the Tolerance Advisor to review informational messages and warnings on the tolerance features in a model.
• Creating a general profile note annotation.

Prerequisites
Knowledge of GD&T required. The international GD&T standard, ASME Y14.5M-1994, governs how annotations should be added to clearly describe the model's intent. This learning guide assumes that you know how the model is to be annotated and aims to only explain how they are added using the Autodesk Inventor software.
