Solid Edge 2021 Basics and Beyond: Black & White - Paperback

by Online Instructor (Author)

Solid Edge 2021 Basics and Beyond provides the student or practicing engineer with a basic introduction to 3D modeling using Solid Edge 2021. The topics are laid out in step-by-step format with examples and exercises at the end of each chapter to practice the concepts covered. The author uses numerous computer screenshots to explain software features.

Solid Edge is different from the other Computer Aided Designing software. It offers a rich set of tools known as Synchronous Modeling tools, which help you create and edit design concepts quickly and easily. Also, it helps you to design models keeping in mind the final design intent. However, you are required to know the rules of this software to avoid any errors. This book will be helpful if you are beginning to learn Solid Edge.

Table of Contents

1. Getting Started with Solid Edge 2021

2. Sketch Techniques

3. Extrude and Revolve Features

4. Placed Features

5. Patterned Geometry

6. Sweep Features

7. Loft Features

8. Additional Features and Multibody Parts

9. Modifying Parts

10. Assemblies

11. Drawings

12. Sheet Metal Design

13. Surface Design

14. Subdivision modeling
